VisionGauge® Machine Vision / Image Analysis software

VisionGauge® can also be customized – quickly and cost-effectively – to meet the requirements of your specific application

  • Real-Time Full Color Image Acquisition
  • General Imaging & Visual Inspection
  • Image Archiving & Retrieval
  • Image Printing
  • Image Exchange & Transmission
  • Image Annotation
  • Image Retouching & Enhancement
  • Image Processing
  • Image Comparison, Overlay, & Differencing
  • Image Analysis Software
  • Image Blending (“Perfect Focus”)
  • High Precision Measurements & Measurement Statistics
  • Counting & Sizing Particles, Grains, Cells, and other Discrete Objects
  • Image Data Collection, Analysis, Databasing & Exchange
  • Video Sequence Capture & Analysis
  • Inspection & Measurement Report Generation

Reporting, Applications, and System Integration

VisionGauge® visual measurement software also has an integrated report generator that you can use to quickly and easily produce illustrated inspection reports containing measured data, imported images, and data into a database. In addition, VisionGauge® has the ability to transfer measurement results to DDE enabled programs and to automatically export measurements to Microsoft’s Excel.

VisionGauge® runs on all versions of Windows™ and is regularly updated. A full year membership to our renewable Annual Support and Update Program is included, which entitles you to receive free updates and unlimited support by phone, fax and Email.

VisionGauge® is very competitively priced and can be supplied as complete vision systems or vision inspection workstations, including computer, optics, lighting, camera, and motorized or manual positioning/focusing mechanisms, or as a board level and software product.

Insights About This Software

Editions & Spec Sheets

Machine Vision Systems

Annual Support & Update Program (ASUP)

Applications

VisionGauge® comes in several editions, each with features designed for your vision system configuration and application needs:

Main VisionGauge® spec. sheet

VisionGauge® Standard Edition:

  • Powerful and easy-to-use image capture and analysis software with a wide variety of high-accuracy inspection and measurement tools.

VisionGauge® Manual Stage Edition:

  • Supports high-accuracy manual stage-based measurements with DRO display.

VisionGauge® Motorized Stage Edition:

  • Includes support for fully-automated, high-accuracy motorized stage-based measurements and auto-reporting.

VisionGauge® HT for Hardness Testing:

  • Automatically determines the hardness of materials by measuring characteristic dimensions on indentations made by standard Hardness Testing machines.

VisionGauge® software is often supplied as part of a complete vision system. These systems may include specialized components and configurations to solve applications with difficult requirements, or they may be generalized to solve a wide-variety of different inspection applications at the same workstation. VISIONx, Inc. is accustomed to customizing inspection systems to meet specific application needs, all with our powerful and easy-to-use VisionGauge® software interface.

VisionGauge® is readily integrated into AOI Systems, Fully-Automated High-Accuracy 3D Measurement Systems, Cartesian Measurement and Inspection Systems, Portable Inspection Systems, and much, much more. View our Machine Vision Systems section for examples of the complete vision systems we have provided with VisionGauge® software.

VisionGauge® software products are being continuously developed to add new tools and enhance existing tools, support new versions of Windows®, devices, and hardware, fix/update any problems, and generally improve performance. These enhancements allow our systems to solve new applications and improve the performance of current applications in the field. This approach has allowed us to update existing systems that were originally installed with Windows® 98 20+ years ago to the latest version of Windows® with up-to-date hardware without requiring users to purchase a new software license.

Contact us to learn more about our VisionGauge® Annual Support and Update Program (ASUP), allowing members access to unlimited Technical Support and software updates.

VisionGauge® software and products are being used across numerous industries to solve a vast array of machine vision and visual inspection applications. View our machine vision application sampling to find out how some of our VisionGauge® products are being applied.

Also learn about applications solved with our groundbreaking VisionGauge® Digital Optical Comparator.

Software Features

Create customized measurement reports with indexed keys and thumbnail image search capabilities to quickly retrieve saved results.

VisionGauge® includes support for motorized optical systems, allowing both motorized zoom and focus to carry out high-accuracy measurements over the full zoom range of the optics.

The VisionGauge® Motorized Stage edition features several exclusive software tools, including:

VisionGauge® HT is the ideal software tool to measure the hardness of materials. VisionGauge® Hardness Testing software automatically determines the hardness (Brinell, Knoop, Rockwell & Vickers) by visually measuring characteristic dimensions on indentations made by standard hardness testing machines. VisionGauge® HT carries out all hardness measurements in accordance with the latest revision of the relevant ASTM Standards. And VisionGauge® advanced edge-detection technology produces sub-pixel accurate measurements, increase measurement repeatability and virtually eliminates operator-dependent measurement error.

VisionGauge® HT is a superset of the VisionGauge® feature-rich Standard Edition, which means that it includes the VisionGauge® wide range of measurement and statistics tools, counting & sizing features, reporting & databasing capabilities, image capture, annotation, enhancement, analysis, comparison & transmission features, etc…

As is the case with the entire VisionGauge® family of software products, VisionGauge® HT is very powerful but remains extremely easy to use. Because of its ease of use, VisionGauge® Hardness Testing software is perfectly suited for use on the shop floor as well as in the quality control and production labs.

VisionGauge® is very competitively priced and can be supplied as a board level & software product or as a complete turnkey measurement system. VisionGauge® can also be customized – quickly and cost-effectively – to meet the requirements of your specific application.
